Fluid Hot Thermic Fluid, Hot Water, Steam, Oil, Gas, Actuator Type 3 Way Motorized Control Valve Motorized Plug Valves, Size 150 mm, Model RM3
Active
Premium
Key Highlights
Request Price
MOQ
1
Available Variants
Technical Specifications
| Parameter | Value |
|---|---|
| Body | ASTM A216 Gr. WCB/ASTM A351 Gr. CF8/CF8M |
| Seat | Metal Seated |
| Size | 150 mm |
| Fluid | Hot Thermic Fluid, Hot Water, Steam, Oil, Gas |
| Gears | Steel Hobbed, Toughened Gears |
| Model | RM3 |
| Housing | Aluminum Alloy |
| Actuator | Motorised Actuator |
| Material | S.S. 410 |
| Valve Size | 6.5 inch |
| Type of Plug | On-off |
| Actuator Type | 3 Way Motorized Control Valve |
| Gland Packing | Teflon/Grafoil |
| Electric Motor | Single Phase, Permanent Split Phase Capacitor Type Class F Insulated Motor |
| End Connections | Flanged Ends ANSI B16.5 Cl.150, Cl. 300, PN 16 & PN25 (600 available on request) |
| Pressure Rating | ANSI B16.5 Cl.150, Cl. 300 |
| Automation Grade | Semi-Automatic |
| Temperature Rating | Max 400 degree C |
| Control Suitability | Actuator is suitable for On-Off, Anticipatory, PID control System |
| Minimum Order Quantity | 1 Piece |
| Position on Power fail | Stayput |
Product Description
We offer before the selection available for our customers motorized which may, Plug valves serve as found in various types that include ptfe teflon sleeved, Ci lubricated and pressure-regulated connector valve. Fire, Safe, Cryogenic, Jacketed and, Grunion mounted ibr valves supplied from our team are our specialty. These fittings are manufactured aligned with the set industry ensure optimum, Parameters thus grade of the products produced.
